Equipment Specification Sheet
with Renishaw PH10M motorized probe head and TP20NI probe modules.
Brown & Sharp Xcel Model 765 Coordinate Measuring Machine, 25.6” X 23.6” X 19.7” high measuring range, work capacity of 31.5” x 47.2” x 21.2” high.
Cincinnati Milacron 2216 Cinturn Series CNC Turning Center, Chucker Model with 18” chuck, 4.12” spindle bore, 25.31” maximum turn, 60 hp., 20/1500 rpm.
Cincinnati Milacron 2220 Cinturn Series CNC Turning Center, chucker model with 18” chuck, 4.12” spindle bore, 25.31” maximum turn, 75 hp., 20/1500 rpm.
Okuma Multus B300BB-W Multitasking turning center with 40 tool changer, 10” chuck on the main spindle and 8” chuck on the sub spindle with 2.75” diameter bar capacity, .001° C-axis rotation on main and sub, Iemca VIP 80 EII bar feed, 225° B-axis head index and .001° B-axis rotation, travels of 22.83” X-axis, 6.30” Y-axis, and 36.81” Z-axis
Okuma LB4000 EX big bore CNC Turning Center, 3.15” spindle bore, 12” chuck, 18.90” maximum turn, 59.06” between centers, 50 hp., 30/3000 rpm.
Viper VT-33BL 1000 CNC Turning Center, 3.15 spindle bore, 12” chuck, 22.00” maximum turn, 41.34” maximum turn length, 50HP, 25/2400 rpm.
Citizen E25J Swiss CNC Turning Center, 12’ barfeeder, 1” diameter capacity, sub-spindle, milling capability on the main and sub-spindle.
Hardinge Cobra 65 CNC Turning Center with Iemca magazine bar feeder, 10” chuck, 25C collet chuck, 2.62” max bar diameter, 10.5” maximum turn diameter, 31” maximum turn length, 30 hp., 35/4500 rpm.
Mori Seiki Frontier L CNC Turning Center, 8” chuck, collet chuck, 9.84” maximum turn, 1.77” maximum bar, 19.69” maximum turn length, 10 hp., 12/3500 rpm.
Mitsubishi M-H4A Horizontal Machining Center with 30 tool magazine, 15.75” pallet, 1° increment table rotation, 22.0” x 20.1” x 19.7” Z-travel, 30 hp. High Torque spindle motor, 10/10000 rpm.
Hitachi Seiki H400 Horizontal Machining Center with 30 tool magazine, 15.75” pallet, 1° increment table rotation, 20.0” x 18.0” x 18.0” Z-travel, 10 hp. Spindle motor, 60/6000 rpm.
(2) Toyoda FA450 Horizontal Machining Centers with 40 tool magazine, 17.7” pallet with 1° increment table rotation, 23.62” x 23.62” x 22.0” Z-travel, 30 hp. High Torque spindle motor, 60/14000 rpm.
Toyoda FA450 Horizontal Machining Center with 40 tool magazine, 17.7” pallet, 360,000 position table rotation (full fourth axis), 23.62” x 23.62” x 22.0” Z-travel, 30 hp. High Torque spindle motor, 60/14000 rpm.
21” Harrison Engine Lathe M5000, 12.5 hp., 31/1600 rpm., 28.5” gap, 60” centers, steady rest, digital read-out, 3.12” spindle bore. Clausing-Colchester 17” Engine Lathe, 10 hp., 20/1600 rpm. 48” centers, steady rest, digital read-out, 3.0” spindle bore.
Summit Lathe, 11" diameter, 32” centers, 5 hp.
Lagun Universal Mill, 10” x 50” table with digital read-out, X and Y axis power feed, riser block.
Kondia Universal Mill, 9” x 42” table with digital read-out, X axis power feed.
Optima Precision Drill Grinder, built in optical comparator, .012”-1.00” drill capacity.
Surface grinder, 6” x 12”
H. E. & M. Automatic Production Band Saw, 11” x 9” capacity.
Scotchman Cold Saw, 3.125” capacity, automatic clamping.
Delta 12” vertical Band Saw.
Wellsaw Horizontal Band Saw, 9” x 16” capacity.
Stick, Mig, Tig, and Acy Welding.
Arbor Press, 50 ton hydraulic.
Crane capacity to 2 tons.
Mitsubishi Forklift Truck, model #FG20, 4,000 lb. capacity, pneumatic tires.
SolidWorks 3D Computer Aided Design Software.
GibbsCam 3D Computer Aided Manufacturing Software
CamWorks 3D Computer Aided Manufacturing Software.
Visual Manufacturing software, a fully integrated financial and manufacturing system with a superior resource scheduling module that allows for accurate job planning, estimating, and cost information.
Easy DNC software for communication to the CNC machines.
In addition to our Coordinate Measuring Machines, we have a full compliment of measuring tools including surface plates, height gages, gage blocks, gage pins to 1”, OD micrometers to 22”, ID micrometers to 24”, Verniers to 24”, dial bore gages to 18”, depth micrometers to 12”, and a Mitutoya profilometer for measuring surface finish.
